Name of the Equipment– I to P converter
Current range– 4 to 20 mA
Pressure range– 3 to 15 psi
Working principle – Flapper nozzle system
Make-ARK automation
Applications– Current to pressure, Pressure to current converter
|
 |
Name of the Equipment– Control Valve Characteristics
Control Valve (Linear)– Pneumatic; Size: ½ “, Input: 3-15 Psig, Air to open, Characteristics: Linear.
Control Valve (equal%)-Pneumatic; Size: ½”, Input: 3-15 Psig, Air to open, Characteristics: Equal %.
Control Valve (quick)-Pneumatic; Size: ½”, Input: 3-15 Psig, Air to open, Characteristics: Quick.
Rotameter– 60-600 LPH
Water Tank– SS, Vessel
Pump-Frictional horse power
Air Regulator– Range 0-5 kg/cm2
Pressure gauge– Range 0-5 kg/cm2 |
 |
Name of the Experiment– Liquid Level Tank
Rotameter– 10- 100 LPH
Process tank– Cylindrical, with acrylic material on the scaled in mm
Supply tank- Stainless steel 1.5 mm thick Material
Pump– Submersible
Electric supply– 230 +/- 10 VAC, 50 HZ, 1 Phase
Capacity of the bottom tank– 15 litres |
 |
Name of the experiment– Temperature controller
Control Unit– PID Digital controller with RS485 communication
Communication– RS485 to USB converter
Temperature Sensor – Type RTD, PT100
Heating Control-PID Solid state relay
Heater– Type Electrical 2 coil, Capacity 3 KW
Rotameter– 50-600 LPH
Process tank– SS, Capacity 1 lit, insulated
|
 |
Name of the experiment– Liquid level tank
Pump power supply– AC230V, 50Hz
RPM– 6500
Level Sensor – Type RTD, PT100
Discharge-800 LPH
Rotameter– 50-600 LPH
Process tank– SS, Capacity 1 lit, insulated
Dimension of the tank– 600WX525DX550Hmm
Software – SCADA
|
 |
Name of the Experiment– Pressure Process controller
Pump power supply– AC230V, 50Hz
RPM- 6500
Level Sensor – Type RTD, PT100
Discharge-800 LPH
Rotameter– 50-600 LPH
Process tank– SS, Capacity 1 lit, insulated
|
