Microwave Communication Lab

The Microwave Lab is well equipped with all required equipment’s like Klystron power supplies, Microwave trainer kits, Directional Couplers etc. to name few Klystron test benches – X band 8.2 to 12.4 Ghz, J band 5.8 to 8.2 Ghz, Gunn set UPS, VSWR meters, RF circuit design trainer, RF signal generators (110 mhz, 150 mhz), RF source (150 mhz) and Digital Storage Oscilloscopes (100mhz, 30mhz).
Microwave integrated circuits, Micro strip antenna, and a modern computerized antenna trainer system (150 mhz) enable the students to do the projects in this field through analysis and design of their own antennas. a new compact range antenna characterizing facility has been set up to measure the radiation characteristics of antennas, especially the patch antennas and active phased array antennas.

Klystron Setup -X Band 8.2–12.4ghz -32 Nos, Klystron Setup -J Band 5.85–8.2 Ghz – 2 Nos,
Gunn Setup X Band 8.2–12.4ghz – 4 Nos, RF Signal Generator -110 Mhz – 3 Nos, RF Signal Generator -150 Mhz – 3 Nos, Antenna Trainer -750 Mhz – 2 Nos, CRO -30 Mhz – 2 Noos, CRO -100 Mhz -18 Nos, Micro Strip Antenna Trainer – 4 to 6 Ghz – 4 Nos
Lab investment: Rs. 53,15,797/-
