Material Characterization Lab

Specifications

Name of the equipment and Make	Broad Specifications	Equipment
Hall Effect Measurement System HMS 5300 Ecopia, South Korea	Working temperature: 80K – 350K Input Current : 1 nA- 20nA Resistivity Range: 10-4- 10-7 Ω/cm Sample dimensions: 5×5mm- 20×20mm 0.51 Tesla permanent magnet Automatic magnetic movement Spring loaded type
Current – Voltage Source meter KEITHLEY	200V : Low current, Dual channel 60 watts 6- 1/2 digits display Current Max/ Min : 10A pulse/ 0.1fA Voltage Max/ Min : 200V/ 100nV
Surface Profile Measurement system KLA – Tencor ALPHA- STEP D-500	30mm scan length Force Range : 0.03 – 15mg Vertical Range : 0- 1200µm Profiler with 2D Acquisition and surface analysis Optical lever sensor head XY Stage movement : 20mm × 80mm Manual stage leveling
