CALYPSO CAD-Based Software
- Visual Metrology concept for creating and maintaining measuring plans.
- Intelligent: rules-based programming sets the detailed parameters, automatic paths, and collision avoidance.
- Powerful: supports a wide range of sensors, high-level tools, formulas, and parameters.
- Better performance with scanning technology.
- Easy creation of measurement plans with object-oriented programming.
- Software and sensor flexibility while measuring
- Easy to customize reports
Some of the research activities undergone are:
- Selection of sampling points for evaluation of flatness using coordinate measuring machine
- Efficient algorithm for roundness evaluation from coordinate measurement data
- Investigation of influence of sampling size and sampling method in measurement of cylindricity
- Comparison of accuracy of flatness obtained by four sampling techniques using coordinate measuring machine
Portable CMM with Laser Scanner
The Faro Portable CMM is most advanced Portable CMM Arm with Laser Line scanning. The device is high on accuracy and left all the other traditional CMM tools and portable inspection equipment out of date. The Faro Portable CMM will allow easy inspection Reverse Engineering or CAD-to-Part scanning anywhere
Specifications
FARO Laser Line Probe V3:
Accuracy: ±35μm (±0.0014 in.)
Repeatability: 35μm, 2σ (0.0014 in.)
Stand-off: 95mm (3.75 in)
The depth of field: 85mm (3.35 in.)
Effective scan width: Near Field 34mm (1.34 in) Far Field 60mm (2.36 in)
Points per line: 640 points/line
Scan rate : 30 frames/second x 640points/line = 19,200 points/sec.
Laser: 660nm, CDRH Class II/IEC Class 2M
The weight of Laser: 370g
Model: Fusion 1.8 m (6 ft):
Single Point Repeatability: 0.046 mm (0.0018 in.)
Volumetric Accuracy: ± 0.064 mm (±0.0025 in.)
FaroArm Weight : 9.5 kg
Axis: 7
Special features
- Use Laser and Hard Probes seamlessly
- Laser scan up to 19,200 points per second
- No intermediary software running in the background
