MAJOR RESEARCH FACILITIES – EQUIPMENTS IN THE CHEMISTRY DEPARTMENT

Name of the equipment and make	8-port inert atmosphere Glove Box – IT Technologies Pte Ltd, Singapore
Year of Installation	2018
Broad Specifications	A complete controlled inert atmosphere glovebox system that has 8 ports which allows four users to work simultaneously. The dual column closed loop circulation and purification system sustains ultra-low oxygen and moisture levels below 1 ppm. The pressure maintenance in the glove box is fully automatic and controlled by PLC.
Cost of the instrument	Rs 20,40,000
Location	School of Bio-engineering Block, 105-B.
Faculty member in charge/ looking after the equipment	Dr. K. Ananthanarayanan/ Dr. G.T. Senthilandavan

Name of the equipment and make	Physical vapour deposition system – SMART COAT 3.0, Hind High Vacuum Company Private Limited, India.
Year of Installation	2018
Broad Specifications	Fully manual controlled high vacuum thermal evaporation system with all necessary interlock protection with source to substrate distance greater than 25 cm which leads to uniform coating with rms roughness less than 2 nm. The system contains diffusion pump to achieve < 2 X 10-6 mbar high vacuum. It has two thermal evaporation sources which can deposit two different materials in a single operation. It has rotatable sample holder with stepper motor controller to control the speed of the rotation which provides uniform coating.
Cost of the instrument	Rs 9,27,000
Location	School of Bio-engineering Block, B105-B.
Faculty member In charge/ looking after the equipment	Dr. K. Ananthanarayanan

Name of the equipment and make	Spin coater – spinNXG-P2, APEX INSTRUMENTS CO. PVT. LTD, India.
Year of Installation	2018
Broad Specifications	SpinNXG-P2 is made to handle larger sized substrates with ease and can achieve high rotational speeds upto 10000 rpm. SpinNXG-P2 comes pre-loaded with integrated lid-interlock ensuring safety during the coating process. It also houses an in-situ dispensing port over the photoresist lid and houses a bigger graphical LCD console to display RPM v/s time graph of the spin protocol in real-time.
Cost of the instrument	Rs. 1,43,000.00
Location	School of Bio-engineering Block, B105-B.
Faculty member In charge/ looking after the equipment	Dr. K. Ananthanarayanan

Name of the equipment and make:	LC/MS, 6230B Time of Flight (TOF), Agilent technologies.
Year of Installation:	2018
Broad specifications
Reduce false positives with better than 1 ppm mass accuracy. Ensure excellent data quality even for ast UHPLC peaks in high-throughput workflows with data acquisition rates up to 44 spectra/second. Identify compounds based on accurate mass, isotopic abundance, and chemical composition using Find by Formula in Mass Hunter software. Characterize large biologic compounds with a broad mass range of up to 20,000 m/z. Separate target compounds from interferences with high-resolution data
Location	New research building, Ground floor, RB 004
Cost of the instrument	Rs 89,00,000/-
Faculty member In charge/ looking after the equipment	Dr. Gopal Chandru Senadi

Name of the equipment and make	Powder X-ray Diffractometer-PANalytical, Xpert3
Year of Installation	September 2017
Broad Specifications	PANalytical, Xpert3powder, X-ray Diffractometer enabled with CRISP technology, pneumatic shutters and beam attenuators, 2nd generation PreFIX technology.
Cost of the instrument	Rs.53,00,000/-
Location	Department of Chemistry, Instruments room I (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. Palash Sanphui

Name of the equipment and make	Thermo Gravimetric Analyzer, Netzsch-STA 2500 Regulus
Year of Installation	March 2015
Broad Specifications	Maximum sample temperature:1600°C, Furnace : RT to 1600°C (heating rate 0.001 to 50 K/min) Temp precision: 0.3KThermocouple: Type S, Atmosphere: Vaccum- tight 10-4 m bar
Cost of the instrument	Rs.18,17,045/-
Location	Department of Chemistry, Instruments room II (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. Soumyajit Ghosh

Name of the equipment and make	Electrochemical Analyzer & RRDE-CHI608E-3A
Year of Installation	2018
Broad Specifications	Size 190 x (Base: 230, Body: 120) x 400 mm Weight 6 kg Rotational range 100 to 8,000 rpm Rotation stability Error, < 1% at 100 to 1,000 rpm < 0.5% at > 2,000 rpm Ring/Disk insulation resistance> 10 M ohm Electrode to lead pin contact resistance 5 ohm Rotator shaft Stainless steel Motor 12 V, ironless core, low inertial DC servo Power 100-240 VAC, 50/60 Hz Operating temperature 10 to 50°C Relative humidity ≤ 80% Inlet gas pressure 5 psi (34 KPa) maximum Remote control One volt corresponds to 1,000 rpm Motor ON/OFF TTL or relay input to back panel connection Purge TTL or relay input to back panel connection
Cost of the instrument	Rs.14,09,426/-
Location	New research building, RB 101
Faculty member In charge/ looking after the equipment	Dr. S. Karthikeyan

Name of the equipment and make	Electrochemical Analyzer & RRDE-CHI608E-3A
Year of Installation	July 2017
Broad Specifications	Electrochemical Workstation with Potentiostat / GalvanostatLatest Windows Based Acquisition s/w also includes power supply 220V/50HzInterface Cable for USB Port, Cell Cable, Manuals & InstallationLicensed & Full version of software for Electrochemistry & all the techniquesRotating Ring Disk Electrode Apparatus with purge & stir facilityIntegration of control unit and rotator . Both remote and manual operations of rotating and purging system.Various kinds of working electrodes and easy replacing procedure
Cost of the instrument	Rs.13,00,000/-
Location	UB, 13th floor, 1301 Lab-4
Faculty member In charge/ looking after the equipment	Dr. Swami Anita Subhash

Name of the equipment and make	Electrochemical Workstation, Autolab
Year of Installation	November 2017
Broad Specifications	Electrode connections 2, 3 and 4. Potential range +/- 10 V Compliance voltage +/- 10 V. Maximum current +/- 100 mA, Current ranges 10 mA to 10 nA Potential accuracy +/- 0.2 % Potential resolution 3 µV Current accuracy +/- 0.2 % Current resolution0.0003 % (of current range)Input impedance > 100 GOhmPotentiostat bandwidth 1 MHz Computer interface USB-Control software NOVA
Cost of the instrument	Rs.10,81,200/-
Location	UB 13th floor R-36
	Dr. T. Maiyalagan

No data was found

Name of the equipment and make	Potentiostat-galvanostat- Biologic SP-300
Year of Installation	April 2017
Broad Specifications	Upto2 channels, Compliance: ±12 V up to ±49 V with booster, Control voltage: ±10 V upto±48 V with boosterPotential resolution: 1 µV, EIS measurement: 10 μHz – 3 MHz (1%, 1°), 10 μHz – 7 MHz (3%, 3°)
Cost of the instrument	Rs.7,56,136/-
Location	UB, 13th floor, R-36
Faculty member In charge/ looking after the equipment	Dr. T. Maiyalagan

Name of the equipment and make	Rotating Ring Disk Electrode
Year of Installation	August 2017
Broad Specifications	Linear Sweep Voltammetry, Cyclic Voltammetry Chronoamperometry Pulsed Voltammetry (SCP, NPV, DPV & SWV) OCP Measurement Tafel Analysis Linear Polarization
Cost of the instrument	Rs.1,73,696/-
Location	New research building, RB 101
Faculty member In charge/ looking after the equipment	Dr. S. Karthikeyan

Name of the equipment and make	Multi-Channel Battery Cycler System- WonA Tech battery cycler.
Year of Installation	2018
Broad Specifications	Multi-Channel Battery Cycler System WBCS3000K8 with Impedance Analyzer
Cost of the instrument	Rs.13,48,572/-
Location	New research building, RB 101
Faculty member In charge/ looking after the equipment	Dr. Prasant Kumar Nayak

Name of the equipment and make	Tyrone – Camarero- DS30OTR-28R
Year of Installation	August 2017
Broad Specifications	Intel Broadwell Microarchitecture, Processor – Intel – Xeon – E5-2697 V4 Core – 18, Processor Speed – 2.3GHz 64 bit, Chipset Type – Intel C612 Processor Main Features – Hyper –Threading Technology, Intel QuickPath Interconnect, Intel Turbo Boost Technology 2, Cache Per Processor – 45MB Level 3, DDR4 SDRAM Memory Speed – 2400MHz ,Memory – 512 GB, Max Memory Supported – 1536 GB,storage:2x4TB SAS 7200K RPM 3.5
Cost of the instrument	Rs.9,91,526/-
Location	HPCC, SRM IST
Faculty member In charge/ looking after the equipment	Dr. M. Prakash

Name of the equipment and make	Gas Chromatograph,Claraus 580 & Perkin Elmer
Year of Installation	2018
Broad Specifications	The Gas Chromatography instrument is equipped with FID, TCD with online injection system
injection system Cost of the instrument	Rs.9,79,689/-
Location	Department of Chemistry, Instruments room II (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. L. Sivachandiran

Name of the equipment and make	FT-IR, SHIMADZU IR TRACER-100
Year of Installation	2018
Broad Specifications	IR REGION 400-12500 cm-1, STANDARD KBr MODE, ATR MODE, SRM, DRS.
Cost of the instrument
Location	New research building,Ground floor,RB 004
Faculty member In charge/ looking after the equipment	Dr. L. Sivachandiran

Name of the equipment and make	Double beam UV-Vis Absorption Spectrometer, Labman, 1900S
Year of Installation	February 2015
Broad Specifications	Optical System Double Beam, Grating 1200 lines / mm, WavelengthRange190 – 1100nm, Scanning SpeedFast, Medium & Low. Photometric Accuracy+0.3%T, Photometric Repeatability+ 0.2%TPhotometric Range -0.3-3A,0-200%.
Cost of the instrument	Rs.3,00,000/-
Location	Department of Chemistry, Instruments room II (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. M. Mariappan

Name of the equipment and make	Tintometer Lovibond-Spectrodirect with Thermoreactor RD 125.
Year of Installation	September 2015
Broad Specifications	Spectrodirect Wavelength range from 330 to 900 nm The RD 125 reactor is fitted with 24 holes for 16mm diameter vials. With the voltage switch on the back 220 V and 110 V are selectable.
Cost of the instrument	Rs. 4,79,985/-
Location	Department of Chemistry, Instruments room II (MCA Block)
Faculty member In charge/ looking after the equipment

Name of the equipment and make	Gel documentation System- Gelstan (SLV biosolution)
Year of Installation	September 2016
Broad Specifications	Gel documentation system, Gel Stan 1312 Advances, Bioworld-Midi Submarine Gel Electrophoresis with power supply and incubator.
Cost of the instrument	5,70,000/-
Location	Department of Chemistry, Instruments room II (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. M. Ganesh Pandian

Name of the equipment and make	POLARIZING MICROSCOPE, BA310 POL, MOTIC
Year of Installation	2017
Broad Specifications	Widefield high eyepoint, N-WF10X/20mm, diopter adjustment on both eyepieces, Intermediate tube with rotatable analyzer 360º and Bertrand lens, focusable Quartz wedge, full λ and 1/4λ retardation plates. Reversed quadruple nosepiece with click stops for precise magnification changes, individually centrable with one reference position CCIS EC Plan Strain-free objectives EC PL 4X/0.10, 10X/0.25, 40X/0.65-Spring, 60X/0.80-Spring Coaxial coarse and fine focusing system with 2 micron minimum increment with tension adjustment. Vertical travel range 20mm360º circular rotating stage with a diameter of 160mm, lockable positionFocusable Rotatable polarizer, fixed on condenser carrier
Cost of the instrument	Rs.4,82,352/-
Location	Department of Chemistry, Laboratory 4 (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. Soumyajit Ghosh

No data was found

Name of the equipment and make	: MIXER MILL, MM 400,RETSCH
Year of Installation	2017
Broad Specifications	Reproducible, efficient grinding, mixing and homogenization in seconds powerful grinding by impact and friction, up to 30 Hz for up to 20 samples per run3 different grinding modes (dry, wet or cryogenic)screw-top grinding jars for leak-proof grinding9 SOPs can be stored wide range of accessories including various jar and ball sizes, adapter racks for single use vials and tubes, grinding tool materials
Cost of the instrument	Rs.6,21,410/-
Location	Department of Chemistry, Laboratory 4 (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. Soumyajit Ghosh

Name of the equipment and make	AC System Source Meter, TEKTRONIX
Year of Installation	July 2017
Broad Specifications	TEKTRONIX AC System Source Meter – Dual ChannelModel : 2612B IManual Triple Channel DC Power SupplyModel : 2231A-30-3.
Cost of the instrument	Rs.5,02,072/-
Location	New research building, RB 101
Faculty member In charge/ looking after the equipment	Dr. S. Karthikeyan

Name of the equipment and make	PROBE STATION- KEITHLEY and HYDRO PNEO VAC TECHNOLOGIES
Year of Installation	July 2017
Broad Specifications	Probe Station: X, Y, Z movement of at least 7mm with a precision of 0.5mm per turn with Tungsten probe to measure DC Current with magnetic Base, Probe station-X, Y, Z movement of at least 7mm with a precision of 0.5mm per turn with Tungsten probe to measure DC Current with magnetic Base
Cost of the instrument
	Rs.3,39,500/-
Location	New research building, RB 101
Faculty member In charge/ looking after the equipment	Dr. S. Karthikeyan

Name of the equipment and make	Online NO and NO2 Gas analyzer OMGA -20170062 &Vasthi Instruments PVT.LTD
Year of Installation	2018
Broad Specifications	The NO/NO2 can be detected in real-time using online analyzer
Cost of the instrument	Rs.3,87,040/-
Location	Department of Chemistry, Instruments room II (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. L. Sivachandiran

Name of the equipment and make	Mass flow controllers (MFC) DF-300,KOFLOC
Year of Installation	2018
Broad Specifications	: For Specific gas O2, NO, H2, CO2, CH4, N2 Maximum 0.100 -2.0 LPM flow rate respectively
Cost of the instrument	Rs.4,59,958/-
Location	Department of Chemistry, Instruments room II (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. L. Sivachandiran

Name of the equipment and make	Oscilloscope DSOX2002A &Keysight Technology
Year of Installation	2018
Broad Specifications	Device used to display and analyze the waveform of electronic signals
Cost of the instrument	Rs.75000.00
Location	Department of Chemistry, Instruments room II (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. L. Sivachandiran

Name of the equipment and make	Glove Box- Aero Glove Box
Year of Installation	August 2016
Broad Specifications	Glove box with single user
Location	Department of Chemistry, Laboratory 3 (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. Baburaj Baskar

Name of the equipment and make	Hydrogenator- Shakthi Instruments
Year of Installation	August 2017
Broad Specifications	Hydrogenatorwith oscillator and heating controller (0-100° C)
Cost of the instrument	Rs.68700/-
Location	IIISM-SRM- IST-II floor
Faculty member In charge/ looking after the equipment	Dr. BABURAJ BASKAR

Name of the equipment and make	UV Reactor, LUZCHEM- LZC-4V
Year of Installation	2017
Broad Specifications	Dimensions-External: 18″ wide, 21″ deep (with exhaust), 16.5″ high (46 x 53 x 42 cm) Internal: 12″ wide, 12″ deep and 8.5″ high (30 x 30 x 22 cm) Power Rating: 110 VAC/220 VAC, 50/60 Hz cycle, 3 Amps Ships with North American-style power cable Ambient Temperature: Must be between 10ºC and 35ºC Humidity: 0% and 95% (non-condensing) Chamber Temperature: Maintained to 4-5ºC above room temperature
Cost of the instrument
Location	Department of Chemistry, Laboratory 4 (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. Soumyajit Ghosh

Name of the equipment and make	MELTING POINT APPARATUS, VEEGO
Year of Installation	2017
Broad Specifications	MODEL: VMP-PM Specifications: Incorporated with magnifying lens permitting clear view of sample under test. Validation Program for Standard samples.8 Operator names can be stored. Graphic LCD Display to display all test parameters & test instructions. Memory to store around 100 test records. Facility for testing UNKNOWN sample.Temperature range: Room temperature +2 °C – 300 °C. Temperature resolution: 0.1 °C. Heating rate: 1 °C/minute (Starts from set temperature – 10 °C). Input: Tactile Keyboard + PS – 2 keyboard
Cost of the instrument	Rs.95,000/-
Faculty member In charge/ looking after the equipment	Dr. Soumyajit Ghosh

No data was found

Name of the equipment and make	Microscope Camera, MC170 HD, Leica
Year of Installation	2017
Broad Specifications	5 MP HD Microscope Camera Leica MC170 HD. HD Digital microscope camera with c-mount interface that provides a full high definition live image with up to 30fps and a standard capture resolution of 5Mpixels. It produces full-color still images for all microscopic applications. The camera can be used standalone without PC or Connected via USB cable. In PC mode the camera offers full compatibility with LAS and its many add-on modules like interactive measurement or extended focus.
Cost of the instrument
Location	Department of Chemistry, Laboratory 4 (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. Soumyajit Ghosh

Name of the equipment and make	Rotary Evaporator, RV – 10 digital V, Make: IKA, Germany
Year of Installation	August 2016
Broad Specifications	Rotary evaporator with KNF Vacuum pump, and Indigenous Chiller.
Cost of the instrument	Rs. 3,90,000/-
Location	Department of Chemistry, Laboratory 2 (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. Baburaj Baskar

Name of the equipment and make	Super fit Rotary evaporator- Super Vac
Year of Installation	April-2016
Broad Specifications	Rotary evaporator with high efficient vaccum pump and digital rpm display, bath with digital temperature controller.
Cost of the instrument	Rs. 2,87,853/-
Location	Department of Chemistry,Laboratory 2 (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. S. Ganesan

Name of the equipment and make	Muffel Furnace-Hasthas scientific
Year of Installation	March 2017
Broad Specifications	Heating temperature upto Max-1000°c
Cost of the instrument	Rs.27,300/-
Location	New research building, RB 2nd floor
Faculty member In charge/ looking after the equipment	Dr. T. Maiyalagan

Name of the equipment and make	Tubular furnace-Ants Innovations.Pvt.Ltd.
Year of Installation	August 2017
Broad Specifications	Heating temperature Max-1000°c
Cost of the instrument	: Rs.1,15,203/-
Location	New research building, RB 2nd floor
Faculty member In charge/ looking after the equipment	Dr. T. Maiyalagan

Name of the equipment and make	Furnace Model: ANTS Lab SplitTube Furnace
Year of Installation	May 2017
Broad Specifications	High Temperature split tube furnace upto 1200° C
Cost of the instrument	Rs.1,92,087/-
Location	New research building, RB 101
Faculty member In charge/ looking after the equip	Dr. S. Karthikeyan

Name of the equipment and make	Tubular furnace, JOTHI INDUSTRIAL INSTRUMENT
Year of Installation	Maximum heating temperature 1000 °C Heating zone 300 °C
Cost of the instrument	Rs.27140
Location	Department of Chemistry, Instruments room II (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. L. Sivachandiran

Name of the equipment and make	Tubular Furnace –SuppuSusee Technologies.
Year of Installation	2018
Broad Specifications	Tubular Furnace with temperature controller and heating upto1200°C
Cost of the instrument	Rs.1,43,125/-
Location	Department of Chemistry, Laboratory 7 (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. V. Kumaran

Name of the equipment and make	High voltage probe- ZMHVP-ACDC &Zeal manufacturing and calibration services limited from Pune India
Year of Installation	2018
Broad Specifications	The probe can measure AC/DC voltage from 0-40 kV
Cost of the instrument	Rs.23100
Location	Department of Chemistry, Instruments room II (MCA Block)
Faculty member In charge/ looking after the equipment

Name of the equipment and make	High Voltage Power source, Jayanti transformers
Year of Installation	2018
Broad Specifications	AC High voltage power source with fixed operating frequency of 50Hz. Maximum voltage of 40 kV can be generated
Cost of the instrument	Rs.1,49,000.00
Location	Department of Chemistry, Instruments room II (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. L. Sivachandiran

No data was found

Name of the equipment and make	MC5SLM MFC &Alicat scientific Inc
Year of Installation	2018
Broad Specifications	For Non-Corrosive gas Maximum 2.0 LPM flow rate,an accuracy of ±0.8% at STP
Cost of the instrument	Rs.78858.30
Location	Department of Chemistry, Instruments room II (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. L. Sivachandiran

Name of the equipment and make	Precision disc cutter for CR2032 (Xiamen Tmax)
Year of Installation	2018
Broad Specifications	Precision coin cell battery disc cutter machine
Cost of the instrument	Rs.57,789.00
Faculty member In charge/ looking after the equipment	Dr. Prasant Kumar Nayak

Name of the equipment and make	BALL MILL- RAJDHANI MAKE.
Year of Installation	2018
Broad Specifications	BALL MILL- RAJDHANI MAKE- UPTO (1KG SS JAR)
Location	New research building, RB 101
Faculty member In charge/ looking after the equipment	Dr. Prasant Kumar Nayak

Name of the equipment and make	HOT AIR OVEN
Year of Installation	July 2017
Broad Specifications	Construction Triple walled Temp range5oC to 300o c Dimensions 455455455 mm Power 230 V
Controller Digital temp. controller	Auto heater Available.
Cost of the instrument	Rs.63,525
Location	UB, 13th floor, 1301 Lab-4
Faculty member In charge/ looking after the equipment	Dr. Swami Anita Subhash

Name of the equipment and make	HOT AIR OVEN-TECHNICO
Year of Installation	2017
Broad Specifications	TEMPERATURE CONTROLLED HOT AIR OVEN
Cost of the instrument	Rs.18,000
Location	Department of Chemistry, Laboratory 3 (MCA Block)
Faculty member In charge/ looking after the equipment	: Dr. S. Shanmugan

Name of the equipment and make	Centrifuge- REMI-R24
Year of Installation	July 2017
Broad Specifications	Stepless speed regulator with zero start interlock, Digital speed indicatorDynamic brake, 0-99 minutes digital count down timer, Imbalance detector with cutoff, Safety lid interlock to prevent cover opening during centrifugation.
Cost of the instrument	Rs.62,483
Location	UB, 13th floor, 1301 Lab-4
Faculty member In charge/ looking after the equipment	Dr. Swami Anita Subhash

Name of the equipment and make	Digital ultrasonic cleaner with lid timer & heater
Year of Installation	March 2017
Broad Specifications	Heating from ambient to 80° C with digital timer
Cost of the instrument	Rs.9975
Location	New research building, RB 2nd floor
Faculty member In charge/ looking after the equipment	Dr. T. Maiyalagan

Name of the equipment and make	BATH SONICATOR LABMAN
Year of Installation	July 2017
Broad Specifications	Capacity6.5 L,Temp. rangeRT to 70o c , Dimensions 320260100Power 150 watts Time Range 0-90 min Rated supply 170 to 27 vac
Cost of the instrument	Rs.40,583
Location	UB, 13th floor, 1301 Lab-4
Faculty member In charge/ looking after the equipment	Dr. Swami Anita Subhash

Name of the equipment and make	Labman Ultrasonic cleaner 1.8lit Digital LMUC-2
Year of Installation	2018
Broad Specifications	: Digital ultrasonic cleaner with lid timer & heater, Heating range from ambient to 80°C
Cost of the instrument	Rs.9300
Location	Department of Chemistry, Laboratory 4 (MCA Block)
Faculty member In charge/ looking after the equipment	Dr. D. Paradesi

No data was found

No data was found

No data was found
